Low Carbon Galvanized OD 10-3/4" Sand Control 1.0mm Johnson Wire Screen

Brand Name : Hengyuan

Model Number : 10-3/4" (273mm)

Certification : ISO, CIQ, CE, SGS

Place of Origin : Anping, Hebei , China

MOQ : 1 piece

Payment Terms : D/A, L/C, D/P, T/T, Western Union, MoneyGram

Supply Ability : 300 meters per day

Delivery Time : 7 days

Packaging Details : plastic film in contaciner or woonen boxes

Material : Low Carbon Galvanized

Slot : 1.0mm

End connection : Welded rings

Filter type : From outside to inside

Standard length : 5.8m

Wire shape : 3*4.6mm V shaped

Support rod : ø4.0mm round wire

Open area : 25%

Contact Now

10-3/4" Low Carbon Galvanized Johnson Wire Screen For Sand Control

Johnson wire screen also be named: Johnson screen, Johnson well screen, Wedge wire screen

Wound screen, Wire wrapped wire, Water well screen, Countinuous slot well screen,

Water filter nozzle, Wedge wire mesh, Wedge wire screen panel, Sand control screen

Wedge wire screen pipe, Wedge wire screen tube, Rotary filter drum

Downhole slotted tube, Taper steel tube, Stainless steel screen tube

Galvanized screen, Wedge wire slot tubes, Wire screen cylinder

Product Name Johnson Wire Screen
Material Stainless steel 304
Length 5.8m
Standard SY/T5182-2008
Diameter 10-3/4" (273mm)
End connection Welded rings on two ends
Slot size 1.0 mm
Surface Polish

Johnson Wire Screen Information:

1. Grade:SS 201, 304, 316, or low carbon galvanizd steel ,hastelloy,titanium, 904L etc..

We don't have ready goods, We will start product after we sign order.

2. Size: execpt 12", we can also make 2", 3", 4", 5", 6", 7", 8", 9", 10", 14", 16" and so on.

3. Standard: 2.9m/5.8m to fit container.

Sizes

(inch)

OD

(mm)

Slot

(mm)

Length

(m)

Tenslie

Strength

Collapse Strength

Wrap wire

(Width*height)(mm)

Support rod

Round wire

(mm)

3-1/2 88.9 1.0 3 >22 10.2 2.3*3.5 3.8MM/22
4-1/2 114.3 1.0 3 >28 11.5 2.3*3.5 3.8MM/22
6-5/8 168.3 0.75 5.8 >40 12.8 2.3*3.5 3.8MM/32
6-5/8 168.3 1.0 5.8 >33 12.8 2.3*3.5 3.8MM/32
6-5/8 168.3 0.63 5.8 >83 45 3.2*6.0 6.0MM*32
8-5/8 219.1 1.0 5.8 >34 21.9 2.3*3.5 3.8MM/48
8-5/8 219.1 1.0 5.8 >50 38.2 3.0*5.0 4.0MM/48
8-5/8 219.1 1.0 5.8 >60 46 3.2*6.0 5.0MM/48
10-3/4 273.1 0.75 5.8 >50 32.9 2.3*3.5 4.9MM/55
10-3/4 273.1 1.0 5.8 >60 39.5 3.0*5.0 4.9MM/55
10-3/4 273.1 1.0 5.8 >100 48 3.2*6.0 5.0MM/55
12-3/4 323.9 1.0 5.8 >120 37.2 3.0*5.0 4.0MM/50
14 355.6 1.0 3 >80 37.8 3.0*5.0 4.0MM/59

Usage:

The all welding wire wrap screen can be used in petroleum, gas and water well, filling with gravels, can prevent the sand and protect the equipment in the well and underground, prolong the life span. It has the characteristics of easy operation, fine permeability, unaffected by temperature, long life service, safety and reliability, low comprehensive cost and etc.

FAQ

Q: Are you trading company or manufacturer ?

A: We are manufacturer for more than 15 years.

Q: How long is your delivery time?

A: Generally we need 10 days if the quantity isn't very big.

Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample for free charge but do not pay the cost of express.
